Aluminum Decking C-60 Plank Extrusion - Information For Landscape Architects and Designers

Description:
Major structural element used in Versadeck™ Commercial Aluminum Decking Systems; Versaplank™, Versadry™ and Versamods™.

Commercial Aluminum Decking Plank Image by Versadeck

Specifications/Properties

Wall Thickness: .092    Break Corners: .130 R    Alloy: 6063    Temper: T6    Shape: Solid   Weight per LN FT: 2.120    Width: 5.625 IN    Height: 1.496 IN   Area: .9489    Perimeter: 18.262

Determination of maximum safe span

Calc. section modulus = 0.24 For a 60" span -  loading capacity = 360 psf One plank center load capacity = 272#

Deflection test with 50# load at center of plank

60" span - deflection = 3/32" = 0.09" (60 psf live load) 60" span - allowable 36/360 deflection = 0.10"

Strong Decking suitable for a 48" span with a SF loading of 100 psf

A 48" span or less for SF loading of 100 psf
A 60" span or less for SF loading of 60 psf
