Aluminum Decking R-40 Plank Extrusion Information For Landscape Architects and Designers


Description

Major structural element used in Versadeck™ Residential Decking Systems; Versaplank™, Versadry™ and Versamods™.

Visual

 Residential Aluminum Decking Plank Image by Versadeck


Specifications/Properties

Wall Thickness: .083 Break Corners: .010 R Alloy: 6063 Temper: T6 Shape: Solid
Weight per LN FT: .746 Width: 5.595 IN Height: .879 IN Area: .623 Perimeter: 17.163

Determination of maximum safe span

Calculated section modulus of plank = 0.24
For a 36" span - loading capacity = 356 psf
plank center load capacity = 269#

Deflection test with 50# load at center of plank

36" span - deflection = 3/32" = 0.09" (60 psf live load)
36" span - allowable 36/360 deflection = 0.10"

Strong Decking suitable for a 36" span with a SF loading of 60 psf

A 24" span is recommended to produce a more rigid deck with a higher center point loading.
